P275GH,P275GH steel plate,P275GH press vessels,DIN EN10273 P275GH steel plate application

P275GH steel plate for press vessels

P275GH is in the standard DIN EN10273 . DIN EN10273 series steel grades are used to fabric high temperature pressure vessels in Germany standard. There are some alloy steel, like 10CrMo9-10, 11CrMo9-10, 13CrMo4-5, 16Mo3, and also some carbon steel. Some need to be done Normalizing, like P355NH, P460NH, some need to be done Q&T like P355QH, P460QH, P690QH, P500QH

Standard: DIN EN10273
Steel Grade : 10CrMo9-10, 11CrMo9-10, 13CrMo4-5, 16Mo3, P235GH, P250GH, P265GH, P275GH, P295GH, P355GH, P355NH, P355QH, P460NH, P460QH, P500QH, P690QH
Dimension range :1.5 mm -300mm x 1000mm-4000mm x 1000mm-18000mm
MOQ: 1 PC
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : 10CrMo9-10,13CrMo4-5, 16Mo3, P235GH, P265GH, P295GH, P355GH, P355NH, P460NH are Available
MTC: Available
Payment Term : T/T or L/C At sight .

P275GH steel plate main description :
P275GH steel plate is a kind of material for boiler and pressure vessel steel. P275GH steel is mainly used to for manufacturing boilers, pressure vessels and pipes transporting hot liquids.

P275GH steel chemical composition :

Grade	C	Si ≤	Mn ≤	P ≤	S ≤	Cr ≤	Mo ≤	Ni ≤
P275GH	≤0.18	0.40	0.50~1.40	0.030	0.025	≤0.30	≤0.08	≤0.50

P275GH steel plate production details:

Grade	standard	thickness	width	length	shape
P275GH	EN10273	6-200mm	1500~4500mm	6000-18000mm	plate

P275GH steel plate Delivery details:
the use of state according to user requirements, can press rolling (AR), hot rolling (CR), mechanical controlled rolling accused of cold (TMCP), is fire (N), tempering (T), annealing (A), quenching (Q), adjusting quality (QT) and so on the different state delivery.

P275GH steel plate application :
P275GH pressure vessel steel is widely used in petroleum, chemical industry, power station, boiler, etc, used to make the reactor, heat exchanger, separator, liquefied gas, nuclear reactor pressure vessel, boiler steam drum steam, liquefied petroleum, hydropower station, high pressure pipe, spiral case and other equipment and components.

Shanghai Royal Industry is a professional super steel plates/sheets manufacture and supplier. We can supply different product type of 10CrMo9-10, 11CrMo9-10, 13CrMo4-5, 16Mo3, P235GH, P250GH, P265GH, P275GH, P295GH, P355GH, P355NH, P355QH, P460NH, P460QH, P500QH, P690QH .If you have any need of DIN EN10273 super heavy steel plate please do not hesitate to contact us .
