JIS G3114 SMA490AW Corten steel, SMA490AW steel plate/Sheet. SMA490AW low alloy high strength atmospheric corrosion resisting steel.
Key words : SMA490AW, JIS G3114 SMA490AW hot rolled steel, JIS G3114 SMA490AW steel plate/sheet/bar/section steel. JIS G3114 SMA490AW Corten steel, SMA490AW Weathering steel, SMA490AW Weathering resistant steel, SMA490AW atmosphere corrosion resistance steel.
JIS G3114 SMA490AW Corten steel widely used in air preheater, economizer, railway carriage, containers production, bridge building , construction and so on.
SMA490AW Weathering steel chemical composition
Grade |
C ≤ |
Si |
Mn ≤ |
P ≤ |
S ≤ |
Cu |
Cr |
Ni |
Ce ≤ |
SMA490AW |
0.18 |
0.15~0.65 |
1.40 |
0.035 |
0.035 |
0.30~0.50 |
0.45~0.75 |
0.05~0.30 |
- |
SMA490AW Weathering resistant steel tensile property
Min Yield Strength ( MPa ) |
Tensile Strength |
Elongation A% |
|||||
Thickness of plates and sections (mm) |
|
|
|||||
≤ 16 |
>16- ≤ 40 |
>40- ≤ 75 |
>75- ≤ 100 |
>100- ≤ 160 |
>160- ≤ 200 |
490-610 |
15 min |
SMA490AW steel delivery condition can be hot rolled, Cold rolled ,AR/CR/N/TMCP/T/QT as the customer request
SMA490AW steel material can be produced as SMA490AW steel plate, SMA490AW steel sheet, SMA490AW steel bar, SSMA490AW section steel, SMA490AW structural shapes
Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled SMA490AW steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find hot rolled and cold rolled SMA490AW steel supplier, hot rolled and cold rolled SMA490AW steel manufacturer, hot rolled and cold rolled SMA490AW steel exporter, please contact Shanghai Royal Industry’s sales team. We will give you the hot rolled and cold rolled SMA490AW competitive price, hot rolled and cold rolled SMA490AW good quality and best service from us.
