JIS G3114 SMA490CP Corten steel, SMA490CP steel plate/Sheet. SMA490CP low alloy high strength atmospheric corrosion resisting steel.
Key words : SMA490CP, JIS G3114 SMA490CP hot rolled steel, JIS G3114 SMA490CP steel plate/sheet/bar/section steel. JIS G3114 SMA490CP Corten steel, SMA490CP Weathering steel, SMA490CP Weathering resistant steel, SMA490CP atmosphere corrosion resistance steel.
JIS G3114 SMA490CP Corten steel widely used in air preheater, economizer, railway carriage, containers production, bridge building , construction and so on.
SMA490CP Weathering steel chemical composition
Grade |
C ≤ |
Si |
Mn ≤ |
P ≤ |
S ≤ |
Cu |
Cr |
Ni |
Ce ≤ |
SMA490CP |
0.18 |
0.15~0.65 |
1.40 |
0.035 |
0.035 |
0.30~0.50 |
0.45~0.75 |
0.05~0.30 |
- |
SMA490CP Weathering resistant steel tensile property
Min Yield Strength ( MPa ) |
Tensile Strength |
Elongation A% |
Impact test |
|||||||
Thickness of plates and sections (mm) |
|
|
Degree |
Energy |
||||||
≤ 16 |
>16- ≤ 40 |
>40- ≤ 75 |
>75- ≤ 100 |
>100- ≤ 160 |
>160- ≤ 200 |
490-610 |
15 min |
0 |
47 |
SMA490CP steel delivery condition can be hot rolled, Cold rolled ,AR/CR/N/TMCP/T/QT as the customer request
SMA490CP steel material can be produced as SMA490CP steel plate, SMA490CP steel sheet, SMA490CP steel bar, SSMA490CP section steel, SMA490CP structural shapes
JW steel keeps more than 10,000 tons hot rolled and cold rolled SMA490CP steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find hot rolled and cold rolled SMA490CP steel supplier, hot rolled and cold rolled SMA490CP steel manufacturer, hot rolled and cold rolled SMA490CP steel exporter, please contact JW steel’s sales team. We will give you the hot rolled and cold rolled SMA490CP competitive price, hot rolled and cold rolled SMA490CP good quality and best service from us.
