JIS G3114 SMA490CW Corten steel plate

JIS G3114 SMA490CW Corten steel widely used in air preheater,economizer,railway carriage,containers production,bridge building,construction and so on.SMA490CW steel delivery condition can be hot rolled,Cold rolled,AR/CR/N/TMCP/T/QT as the customer request.and the size we can offer you of the SMA490CW Corten steel is as follow: Thickness: 6mm to 300mm;Width: 1500mm to 4050mm;Length: 3000mm to 15000mm

SMA490CW weathering steel chemical composition:

Grade	C ≤	Si	Mn ≤	P ≤	S ≤	Cu	Cr	Ni	Ce ≤
SMA490CW	0.18	0.15~0.65	1.40	0.035	0.035	0.30~0.50	0.45~0.75	0.05~0.30	-

SMA490CW weathering resistant steel tensile property:

Min Yield Strength ( MPa )						Tensile Strength	Elongation A%	Impact test
Thickness of plates and sections (mm)								Degree	Energy
≤16	＞16-≤40	＞40-≤75	＞75-≤100	＞100-≤160	＞160-≤200	490-610	15 min	0	47
