SMA570W Corten steel,JIS G3114 SMA570W Corten steel

JIS G3114 SMA570W Corten steel

JIS G3114 SMA570W Corten steel widely used in air preheater,economizer,railway carriage,containers production,bridge building,construction and so on.SMA570W steel delivery condition can be hot rolled,Cold rolled,AR/CR/N/TMCP/T/QT as the customer request.The size we can offer range is Thickness 1-300mm,Width 1000-3000mm,Length 3000-12000mm.

SMA570W Weathering steel chemical composition

Grade	C ≤	Si	Mn ≤	P ≤	S ≤	Cu	Cr	Ni	Ce ≤
SMA570W	0.18	0.15~0.65	1.40	0.035	0.035	0.30~0.50	0.45~0.75	0.05~0.30	-

SMA570W Weathering resistant steel tensile property

Min Yield Strength ( MPa )						Tensile Strength	Elongation A%	Impact test
Thickness of plates and sections (mm)								Degree	Energy
≤16	＞16-≤40	＞40-≤75	＞75-≤100	＞100-≤160	＞160-≤200	570-720	19 min	-5	47

We keeps more than 10,000 tons hot rolled and cold rolled SMA570W steel in stock each month.We can meet our customer’s any quantity request.Based on these stock source,our advantage industry spread into steel process like:cutting ( any size and any shape ) drilling,welding,milling,machining and steel structure.so don’t miss us.
